Kia Cadenza I facelift (2013-2016) memory pwr on/start acc/on i/p crash input Wiring diagram
This page shows the only wiring diagram for the component.memory pwr on/start acc/on i/p crash input, which is found in the car Kia Cadenza I facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory pwr on/start acc/on i/p crash input (1 of 1)
1 13 M-CAN HIGH M-CAN LOW
1 ANT-HD
22 10 FRT MIC - FRT MIC +
A/V, NAVIGATION HEAD UNIT
AUDIO FUSE
BLK WIRE
BLK/ORG WIRE
BRN WIRE
BRN/ORG WIRE
C-CAN LOW C-CAN HIGH
COMPUTER DATA LINES SYSTEM
GRN WIRE
GROUND
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
HSDPA
HSDPA ANT
I/P-B
I/P-C
IPM (LEFT END OF DASH)
JOINT CONNECTOR
LEAK CURRENT AUTOCUT DEVICE
M-CAN LOW M-CAN HIGH
MEMORY PWR ON/START ACC/ON I/P CRASH INPUT
MIC MICROPHONE (LEFT FRONT OF ROOF)
MODULE 2 FUSE
MTS MODULE (CENTER OF DASH)
MULTI MEDIA FUSE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RELAY ENERGIZED
ROOF ANTENNA
SUPPLEMENTAL RESTRAINTS SYSTEM
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Mobile telematic system circuit -> MEMORY PWR ON/START ACC/ON I/P CRASH INPUT
