Kia Cadenza I facelift (2013-2016) high-mounted stop lamp fillter Wiring diagram
This page shows the only wiring diagram for the component.high-mounted stop lamp fillter, which is found in the car Kia Cadenza I facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high-mounted stop lamp fillter (1 of 1)
23 7 8 9 36 34 38 39 32 19 STOP LP SW ESS SIG STP LP RLY CTRL BRK TEST SW RSM
43 21 BRK LIGHT SW BRK TEST SW
BLK WIRE
BLU/RED WIRE
BRAKE SWITCH FUSE
BRN WIRE
BRN/ORG WIRE
ESC UNIT ESC MODULE
ESS SIG
GRN WIRE
GROUND
GRY/BLK WIRE
HIGH MOUNTED STOP LAMP
HIGH-MOUNTED STOP LAMP FILLTER
HOT AT ALL TIMES
I/P-B
I/P-G
INPUT CIRCUIT
INTERNAL CONTROL
IPM IPS (LEFT END CONTROL OF DASH) MODULE
IPS
JOINT CONNECTOR
LEFT "C" PILLAR)
LEFT LICENSE LAMP
LMP SW STOP
LP SIG STOP
NCA WIRE
NOT USED
ORG/ WIRE
PCM (LEFT REAR OF ENGINE COMPT)
POWER MEMORY
RED WIRE
RED/BLK WIRE
RIGHT LICENSE LAMP
ROOM LAMP (DELUXE TYPE)
SIG HAC/DBC
STANDARD PREMIUM
STOP LAMP SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
STOP LP
STOP SIG
TAIL
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Exterior lamps circuit (3 of 3) -> HIGH-MOUNTED STOP LAMP FILLTER
