Kia Cadenza I facelift (2013-2016) dn up front height adjuster switch Wiring diagram
This page shows the only wiring diagram for the component.dn up front height adjuster switch, which is found in the car Kia Cadenza I facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dn up front height adjuster switch (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BWD
BWD FWD SLIDE SWITCH
COMPUTER DATA LINES SYSTEM
DN UP FRONT HEIGHT ADJUSTER SWITCH
DRIVER DOOR MODULE
DRIVER FWD RECLINING SWITCH
DRIVER LUMBAR SUPPORT MOTOR
DRIVER LUMBAR SUPPORT SWITCH FWD
DRIVER MANUAL SWITCH
DRIVER REAR HEIGHT ADJUSTER SWITCH DN
DRV P/SEAT FUSE
E/R FUSE, RELAY BOX (LEFT REAR OF ENGINE COMPT)
GRN/BLK WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
ILL
IMS SWITCH
INTERIOR LIGHTS
J/C
LT GRN WIRE
MCU
NCA WIRE
ORG/ WIRE
RED WIRE
SET-
SYSTEM
TRANSCEIVER IC B-CAN
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Memory seat circuit (2 of 2) -> DN UP FRONT HEIGHT ADJUSTER SWITCH
