Kia Cadenza I facelift (2013-2016) crash pad switch bsd switch Wiring diagram
This page shows the only wiring diagram for the component.crash pad switch bsd switch, which is found in the car Kia Cadenza I facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram crash pad switch bsd switch (1 of 1)
1 2 3 4 5 6 7 8 9 DRV LED + CAN LOW DRV LED -
10 11 12 POWER PASS LED + SHIELD
10 11 12 POWER SW (SIG) SHIELD
5 6 CAN HIGH CAN LOW
7 8 9 C-CAN HIGH
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BSD IND
C-CAN LOW SW (GND) SW (IND)
CAN HIGH
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH BSD SWITCH
DRIVER POWER OUTSIDE MIRROR
GROUND
I/P-D
IPM (LEFT END OF DASH)
LEFT "C" PILLAR)
LEFT BLIND SPOT DETECTION (BEHIND LEFT END OF REAR BUMPER)
MODULE 3 FUSE
NCA WIRE
PASS LED -
PASSENGER POWER OUTSIDE MIRROR
PNK/BLK WIRE
RED WIRE
RED/ORG WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT BLIND SPOT DETECTION (BEHIND RIGHT END OF REAR BUMPER)
WHT/ORG WIRE
YEL WIRE
Go to component -> Blind spot information system circuit -> CRASH PAD SWITCH BSD SWITCH
