Kia Cadenza I facelift (2013-2016) close/ open/ gnd open up tilt close down Wiring diagram
This page shows the only wiring diagram for the component.close/ open/ gnd open up tilt close down, which is found in the car Kia Cadenza I facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram close/ open/ gnd open up tilt close down (1 of 1)
B+ VEHICLE SPEED SIGNAL
BLK WIRE
BLU WIRE
BRN WIRE
CLICK) SWITCH
CLOSE/ OPEN/ GND OPEN UP TILT CLOSE DOWN
CLOSE/ TILT DOWN
CRUISE CONTROL SYSTEM
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
I/P-C
I/P-D
INSTRUMENT CLUSTER
IPM (LEFT END OF DASH)
JOINT CONNECTOR
MODULE
OPEN CLOSE
ORG/ WIRE
OVERHEAD CONSOLE
PANORAMA SUNROOF (CENTER REAR OF ROOF)
PANORAMA SUNROOF SWITCH
RELAY ENERGIZED
STAGE SIGNAL
SUNROOF FUSE
SUNROOF SIG
TILT
TILT UP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> CLOSE/ OPEN/ GND OPEN UP TILT CLOSE DOWN
