Kia Cadenza I facelift (2013-2016) b-can transciver ic Wiring diagrams
This page contains all the electrical diagrams for the component. b-can transciver ic, in which he is found in the car Kia Cadenza I facelift (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram b-can transciver ic (1 of 2)
B-CAN TRANSCIVER IC
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
CONTROL
DOOR SIG
DRIV DR SW
DRIVER DOOR LAMP
DRIVER DOOR MODULE
DRIVER DOOR SCUFF LAMP
DRIVER DOOR SWITCH (DRIVER "B" PILLAR)
DRIVER FOOT LAMP
E/R FUSE,
FOOT LAMP
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
I/P-D
I/P-E
I/P-G
I/P-K
IPM (LEFT END OF DASH)
IPS 7
IPS 7 CTRL
IPS CONTROL MODULE
JOINT CONNECTOR
LAMP
LAMP DRIVER SMART KEY OUTSIDE HANDLE
LEFT "C" PILLAR)
LEFT REAR DOOR SWITCH (LEFT REAR "C" PILLAR)
LR DR SW
MCU
MTR
MULTI FUSE B+2 FUSE RELAY BOX (LEFT REAR OF ENGINE COMPT)
NCA WIRE
PASS DR SW
PASSENGER DOOR SWITCH (PASSENGER "B" PILLAR)
PASSENGER FOOT LAMP
PASSENGER POWER OUTSIDE MIRROR PUDDLE LAMP
PASSENGER SMART KEY OUTSIDE HANDLE
PNK/ORG WIRE
PUDDLE
PUDDLE (LEFT "B" LAMP PILLAR) DRIVER POWER OUTSIDE MIRROR
RED WIRE
RED/BLK WIRE
RIGHT REAR DOOR SWITCH (RIGHT REAR "C" PILLAR)
RR DR SW
TRUNK LID MOTOR (CENTER REAR OF TRUNK LID)
TRUNK ROOF LAMP
TRUNK ROOM LAMP
TRUNK ROOM LAMP SW
TRUNK ROOM LAMP SWITCH
TRUNK, TAILGATE, FUEL DOORS SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit, deluxe type room lamp (2 of 2) -> B-CAN TRANSCIVER IC
Wiring diagram b-can transciver ic (2 of 2)
B-CAN TRANSCIVER IC
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
CONTROL
DOOR SIG
DRIV DR SW
DRIVER DOOR DOOR SWITCH
DRIVER DOOR LAMP
DRIVER DOOR MODULE
DRIVER DOOR SCUFF LAMP
DRIVER FOOT LAMP
FOOT LAMP
GRN WIRE
GRN/BLK WIRE
I/P-G
I/P-K
IPM (LEFT END OF DASH)
IPS CONTROL MODULE
JOINT CONNECTOR
LAMP DRIVER SMART KEY OUTSIDE HANDLE
LEFT REAR DOOR SWITCH (LEFT REAR "C" PILLAR)
LR DR SW
MCU
MTR
NCA WIRE
PASS DR SW
PASSENGER DOOR SWITCH (PASSENGER DOOR "B" PILLAR)
PASSENGER FOOT LAMP
PASSENGER POWER OUTSIDE MIRROR PUDDLE LAMP
PASSENGER SMART KEY OUTSIDE HANDLE LAMP
PNK/ORG WIRE
PUDDLE
PUDDLE (LEFT "B" LAMP PILLAR) DRIVER POWER OUTSIDE MIRROR
RED WIRE
RED/BLK WIRE
RIGHT REAR DOOR SWITCH (RIGHT REAR "C" PILLAR)
RR DR SW
TRUNK DOOR LAMP
TRUNK LID MOTOR (CENTER REAR OF TRUNK LID)
TRUNK ROOM LAMP
TRUNK ROOM LAMP SW
TRUNK ROOM LAMP SWITCH
TRUNK, TAILGATE, FUEL DOORS SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit, general type room lamp (2 of 2) -> B-CAN TRANSCIVER IC
