Kia Cadenza I facelift (2013-2016) 4 5 3 sig 1 gnd vcc Wiring diagrams
This page contains all the electrical diagrams for the component. 4 5 3 sig 1 gnd vcc, in which he is found in the car Kia Cadenza I facelift (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
4 5 3 sig 1 gnd vcc wiring diagram (1 of 2)
4 5 3 SIG 1 GND VCC
8 7 6 VCC SIG 1 GND
B-CAN IC
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
BWD
COMPUTER DATA LINES SYSTEM
DOWN
DRIVER DOOR MODULE
ECU B+
GRN WIRE
GRN/BLK WIRE
GROUND
HOT AT ALL TIMES
I/P-A
I/P-C
I/P-G
I/P-H
ILL
IMS SWITCH
INTERIOR LIGHTS
IPM (LEFT END OF DASH)
IPS CONTROL MODULE IPS CONTROL
J/C
JOINT CONNECTOR
MCU
MODULE 2 FUSE
MOTOR
ORG/ WIRE
P/HANDLE FUSE
RED WIRE
RELAY ENERGIZED
SET-
SIG
SYSTEM
TELE IN
TELE OUT
TELESCOPIC MOTOR (ON STEERING COLUMN)
TILT DOWN
TILT MOTOR (ON STEERING COLUMN)
TILT UP
TILT, TELESCOPIC MODULE (LEFT SIDE OF DASH)
TILT, TELESCOPIC SWITCH
TRANSCEIVER IC B-CAN
VCC
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power tilt & power telescope circuit -> 4 5 3 SIG 1 GND VCC
4 5 3 sig 1 gnd vcc wiring diagram (2 of 2)
4 5 3 SIG 1 GND VCC
B-CAN IC
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
BWD
COMPUTER DATA LINES SYSTEM
DOWN
ECU B+
GRN WIRE
GRN/BLK WIRE
GROUND
HOT AT ALL TIMES
I/P-A
I/P-C
I/P-G
I/P-H
IPM (LEFT END OF DASH)
IPS CONTROL MODULE IPS CONTROL
JOINT CONNECTOR
MCU
MODULE 2 FUSE
MOTOR
ORG/ WIRE
P/HANDLE FUSE
RED WIRE
RELAY ENERGIZED
SIG
SIG (1)
TELE IN
TELE OUT
TELESCOPIC MOTOR (ON STEERING COLUMN)
TILT DOWN
TILT MOTOR (ON STEERING COLUMN)
TILT UP
TILT, TELESCOPIC MODULE (LEFT SIDE OF DASH)
TILT, TELESCOPIC SWITCH
VCC
YEL WIRE
YEL/ORG WIRE
Go to component -> Power tilt steering column circuit -> 4 5 3 SIG 1 GND VCC
