Kia Cadenza I facelift (2013-2016) 31 30 32 33 25 m-can low m-can high c-can low c-can high spd sig wiring diagram
This page shows the only wiring diagram for the component.31 30 32 33 25 m-can low m-can high c-can low c-can high spd sig, which is found in the car Kia Cadenza I facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
31 30 32 33 25 m-can low m-can high c-can low c-can high spd sig wiring diagram (1 of 1)
1 13 16 M-CAN HIGH M-CAN LOW SPD SIG
31 30 32 33 25 M-CAN LOW M-CAN HIGH C-CAN LOW C-CAN HIGH SPD SIG
A/V, NAVIGATION HEAD UNIT
AMP (RIGHT REAR OF LUGGAGE COMPT)
ANALOG CLOCK (RIGHT REAR OF LUGGAGE COMPT)
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
C-CAN HIGH
C-CAN LOW
DRIVER DOOR MODULE
FRONT MONITOR
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY/BLK WIRE
IMS CONTROL MODULE (UNDER DRIVER'S SEAT)
INSTRUMENT CLUSTER
M-CAN HIGH
M-CAN LOW
MDPS MODULE (ON STEERING COLUMN)
NCA WIRE
ORG/ WIRE
PASSENGER DOOR MODULE
SMART KEY CONTROL MODULE (RIGHT CENTER OF DASH)
TILT, TELESCOPIC MODULE (LEFT SIDE OF DASH)
TIRE PRESSURE MONITORING MODULE (RIGHT SIDE OF DASH)
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Computer data lines circuit (2 of 3) -> 31 30 32 33 25 M-CAN LOW M-CAN HIGH C-CAN LOW C-CAN HIGH SPD SIG
