Kia Cadenza I facelift (2013-2016) 1 2 3 4 5 6 memory pwr on/start input tail+ auto cut sig door gnd wiring diagram
This page shows the only wiring diagram for the component.1 2 3 4 5 6 memory pwr on/start input tail+ auto cut sig door gnd, which is found in the car Kia Cadenza I facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
1 2 3 4 5 6 memory pwr on/start input tail+ auto cut sig door gnd wiring diagram (1 of 1)
1 2 3 4 5 6 MEMORY PWR ON/START INPUT TAIL+ AUTO CUT SIG DOOR GND
BLK WIRE
BLU/BLK WIRE
BRN/ORG WIRE
C-CAN TRANSCIVER
COMPUTER DATA LINES SYSTEM
DOOR OPEN IND
DRIVER VANITY LAMP
DRIVER VANITY LAMP SWITCH
GLOVE BOX LAMP)
GRN/BLK WIRE
HOT AT ALL TIMES
I/P-A
I/P-C
I/P-D
INSTRUMENT CLUSTER
INTERFACE
INTERIOR LAMP FUSE
IPM (LEFT END OF DASH)
JOINT CONNECTOR
LEAK CURRENT AUTOCUT DEVICE
LEFT "C" PILLAR)
MCU
MEMORY 1 FUSE
MICOM
MODULE 2 FUSE
ORG/ WIRE
PASSENGER DOOR LAMP
PASSENGER DOOR MODULE
PASSENGER DOOR SCUFF LAMP
PASSENGER VANITY LAMP
PASSENGER VANITY LAMP SWITCH
PUDDLE B-CAN CONTROL TRANSCIVER IC IC
RED WIRE
RED/BLK WIRE
RELAY ENGRGIZED
ROOM LAMP
TRUNK OPEN IND
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit, deluxe type room lamp (1 of 2) -> 1 2 3 4 5 6 MEMORY PWR ON/START INPUT TAIL+ AUTO CUT SIG DOOR GND
