Jeep Wagoneer WS (2021-2024) Pneumatic systems circuit

AIR COMPRESSOR ASSEMBLY BLK WIRE BRN WIRE DK BLU WIRE FUSE 13 FUSE 82 FUSED B(+) FUSED IGNITION FUSED B(+) SWITCH OUTPUT FUSED IGNITION GAUGE GRN/RED WIRE HOT AT ALL TIMES HOT W/ IGNITION RUN 2 RELAY ENERGIZED LED CONTROL LED GND MOTOR MOTOR TEMP SIG PNK/YEL WIRE PRESSURE SIG PRESSURE SWITCH REAR POWER DISTRIBUTION CENTER ASSEMBLY RED WIRE RED/WHT WIRE SENSOR RETURN TEMPERATURE SWITCH TIRE COMPRESSOR GAUGE TIRE COMPRESSOR MOTOR TIRE COMPRESSOR SWITCH WHT WIRE
