Car Wiring Diagrams for Active bodyworks circuit for Jeep Wagoneer WS (2021-2024)

ACTIVE AERODYNAMIC SYSTEM MODULE BLK WIRE CAN FD (-) CLUSTER COMPUTER DATA LINES SYSTEM FUSE 16 FUSE 65 FUSED B (+) CAN FD (+) GRY/TAN WIRE HOT AT ALL TIMES LIN BUS LOWER GRILLE SHUTTER ACTUATOR POWER DISTRIBUTION CENTER ASSEMBLY POWERTRAIN CONTROL MODULE PREMIUM RED WIRE RED/BRN WIRE TAN WIRE WHT/TAN WIRE
