Jeep Wagoneer WS (2021-2024) steering wheel surface comfort module Wiring diagram
This page shows the only wiring diagram for the component.steering wheel surface comfort module, which is found in the car Jeep Wagoneer WS (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering wheel surface comfort module (1 of 1)
3.0L
3.0L 5.7L, 6.4L
5.7L, 6.4L
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR SOLENOID
ACTIVE AERODYNAMIC SYSTEM MODULE
AUXILIARY COOLANT PUMP
BASE
BLK WIRE
CAMERA WASHER MOTOR
CENTER CONSOLE LAMP
CIGAR LIGHTER
CONSOLE POWER OUTLET
COOLER ASSEMBLY
EVAP PURGE SOLENOID
FORWARD FACING CAMERA HEATER
FRONT DE-ICER RELAY
FRONT HVAC BLOWER MOTOR MODULE
FRONT INTEGRATED CENTER STACK MODULE
FUEL PUMP RELAY
HORN 1
HORN RELAY
HUMIDITY RAIN LIGHT MODULE
HVAC MODULE
IGNITION RUN 4 RELAY
INVERTER MODULE
LOWER GRILLE SHUTTER ACTUATOR
OIL PUMP SOLENOID
POWER SIDE STEPS MODULE
PREMIUM
REAR CHARGING USB CONSOLE PORT
REAR UPPER BANK SWITCH
REAR VIEW MIRROR DISPLAY MODULE
REAR WINDOW DEFOGGER RELAY
RUN/ START 1 RELAY
STARTER 2 RELAY
STEERING WHEEL SURFACE COMFORT MODULE
SZ923 (5.7L, 6.4L) SP905 (3.0L)
VVT EXHAUST SOLENOID 1/2
VVT INTAKE SOLENOID 1/1
WASHER CAMERA RELAY
WIRELESS CHARGING PAD MODULE
Go to component -> Ground distribution circuit (3 of 8) -> STEERING WHEEL SURFACE COMFORT MODULE
