Jeep Wagoneer WS (2021-2024) right paddle audio switch Wiring diagrams

This page contains all the electrical diagrams for the component. right paddle audio switch, in which he is found in the car Jeep Wagoneer WS (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

right paddle audio switch wiring diagram (1 of 4)

ANTENNA ANTENNA CABLE ANTENNA SIG BLK WIRE BRN/YEL WIRE CAMERA CABLE CAN C 1 (+) COAX CABLE COMPUTER DATA LINES SYSTEM DK BLU/GRY WIRE DK GRN WIRE DK GRN/BRN WIRE ETHERNET FUSED B (+) FUSED B (+) GND GRY WIRE GRY/BLU WIRE GRY/DK GRN WIRE GRY/GRN WIRE GRY/WHT WIRE GRY/YEL WIRE HORN SWITCH LEFT PADDLE AUDIO SWITCH LEFT STEERING WHEEL SWITCH LIN BUS MUX SIG ORG/VIO WIRE PRIVATE ETHERNET (-) RADIO REAR VIDEO CAMERA RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT INSTRUMENT PANEL SPEAKER RIGHT LIFTGATE SPEAKER RIGHT PADDLE AUDIO SWITCH RIGHT REAR DOOR SPEAKER SCREEN CENTER STACK DISPLAY SOUND SYSTEMS (REAR SEAT ENTERTAINMENT CIRCUIT) STEERING COLUMN CONTROL MODULE STEERING WHEEL CRUISE CONTROL COMMANDS MODULE VIDEO CABLE WHT WIRE WIRELESS CONNECTIVITY/ WIFI ANTENNA YEL WIRE YEL/GRY WIRE

Go to component -> Navigation circuit, premium 3 (5 of 5) -> RIGHT PADDLE AUDIO SWITCH

right paddle audio switch wiring diagram (2 of 4)

ANTENNA ANTENNA CABLE ANTENNA SIG BLK WIRE BRN/YEL WIRE CAMERA CABLE CAN C 1 (+) COAX CABLE COMPUTER DATA LINES SYSTEM DK BLU/GRY WIRE DK BLU/TAN WIRE DK GRN WIRE DK GRN/BRN WIRE DK GRN/GRN WIRE DK GRN/GRY WIRE ETHERNET FUSED B (+) FUSED B (+) GND GRY WIRE GRY/BLU WIRE GRY/DK BLU WIRE GRY/DK GRN WIRE GRY/GRN WIRE GRY/TAN WIRE GRY/WHT WIRE GRY/YEL WIRE HORN SWITCH LEFT PADDLE AUDIO SWITCH LEFT STEERING WHEEL SWITCH LIN BUS MUX SIG ORG/VIO WIRE PRIVATE ETHERNET (-) RADIO REAR VIDEO CAMERA RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT INSTRUMENT PANEL SPEAKER RIGHT LIFTGATE SPEAKER RIGHT PADDLE AUDIO SWITCH RIGHT REAR DOOR TWEETER SPEAKER SCREEN CENTER STACK DISPLAY SOUND SYSTEMS (REAR SEAT ENTERTAINMENT CIRCUIT) STEERING COLUMN CONTROL MODULE STEERING WHEEL CRUISE CONTROL COMMANDS MODULE VIDEO CABLE WHT WIRE WIRELESS CONNECTIVITY/ WIFI ANTENNA YEL WIRE YEL/GRY WIRE

Go to component -> Navigation circuit, premium 4 (5 of 5) -> RIGHT PADDLE AUDIO SWITCH
