Jeep Wagoneer WS (2021-2024) right back seat vent motor Wiring diagram
This page shows the only wiring diagram for the component.right back seat vent motor, which is found in the car Jeep Wagoneer WS (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right back seat vent motor (1 of 1)
BASE
BELOW RIGHT FRONT PASSENGER'S SEAT
BLK WIRE
CENTRAL VISION, PARK ASSIST MODULE
DATA LINK CONNECTOR
FOLD STOW MODULE
PASSENGER DOOR HANDLE LAMP
PASSENGER DOOR LATCH
PASSENGER DOOR MODULE
PASSENGER LUMBAR ADJUSTABLE SEAT SWITCH
PASSENGER MEMORY SEAT MODULE
PASSENGER SEAT MASSAGE MODULE
PASSENGER SEAT SWITCH
PASSENGER SIDE SEAT COURTESY LAMP
PREMIUM
RIGHT BACK SEAT VENT MOTOR
RIGHT CUSHION SEAT VENT MOTOR
RIGHT FRONT COMFORT SEAT MODULE
RIGHT FRONT DOOR BIN MODULE
RIGHT FRONT DOOR SPEAKER LAMP
RIGHT FRONT DOOR SPEAR 1 MODULE
RIGHT FRONT DOOR SPEAR 2 MODULE
RIGHT REAR CUSHION SEAT VENT MOTOR
RIGHT REAR EXTERIOR HANDLE DOOR SWITCH
RIGHT REAR FOOTWELL LAMP
RIGHT REAR SEAT BACK VENT MOTOR
RIGHT REAR SEAT COMFORT MODULE
RIGHT REAR SMART WINDOW MOTOR
W/ MASSAGE SEATS
W/O MASSAGE SEATS
Go to component -> Ground distribution circuit (4 of 8) -> RIGHT BACK SEAT VENT MOTOR
