Jeep Wagoneer WS (2021-2024) recirc dr sig Wiring diagrams
This page contains all the electrical diagrams for the component. recirc dr sig, in which he is found in the car Jeep Wagoneer WS (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram recirc dr sig (1 of 2)
3.0L
5.7L, 6.4L
A/C CLUTCH RELAY
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR SOLENOID
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/PNK WIRE
BLU/TAN WIRE
BLU/WHT WIRE
DEFROST MODE DRV
DK BLU WIRE
DK BLU/BLU WIRE
DK BLU/BRN WIRE
DK BLU/DK GRN WIRE
DK BLU/GRN WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK BLU/YEL WIRE
EVAPORATOR TEMPERATURE SENSOR
FRONT HVAC BLOWER MOTOR MODULE
FRONT MODE DOOR ACTUATOR
FSD B(+)
FUSE 23
FUSE 94
HOT AT ALL TIMES
HOT W/ RUN/START 1 RELAY ENERGIZED
LEFT BLEND DOOR ACTUATOR
LH BLEND DR DRV 1
LH BLEND DR DRV 2
LH BLEND DR SIG
MODE DR SIG
ORG/BLU WIRE
ORG/GRY WIRE
OUTSIDE AIR INLET DRV
PANEL MODE DRV
PNK/VIO WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
PWM CTRL
RECIRC AIR INLET DRV
RECIRC DR SIG
RECIRCULATION DOOR ACTUATOR
RIGHT FLOOR DUCT TEMPERATURE SENSOR
RIGHT PANEL DUCT TEMPERATURE SENSOR
RTN
SIG RTN
SP905 (3.0L) SZ903 (5.7L, 6.4L)
SP905 (3.0L) SZ923 (5.6L, 6.4L)
TAN/DK BLU WIRE
WHT WIRE
WHT/DK GRN WIRE
YEL WIRE
Go to component -> Automatic a/c circuit, quad zone (2 of 5) -> RECIRC DR SIG
