Jeep Wagoneer WS (2021-2024) rear acceleration sensor Wiring diagram
This page shows the only wiring diagram for the component.rear acceleration sensor, which is found in the car Jeep Wagoneer WS (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear acceleration sensor (1 of 1)
BLU/DK GRN WIRE
BLU/GRN WIRE
BLU/TAN WIRE
DK BLU WIRE
DK BLU/BLU WIRE
DK BLU/BRN WIRE
DK BLU/GRN WIRE
DK BLU/GRY WIRE
DK BLU/ORG WIRE
DK BLU/TAN WIRE
DK BLU/VIO WIRE
DK BLU/WHT WIRE
DK BLU/YEL WIRE
GRY WIRE
GRY/BLK WIRE
LEFT FRONT ACCELERATION SENSOR
LEFT FRONT DAMPER VALVE ACTUATOR
LEFT FRONT HEIGHT SENSOR
LEFT REAR HEIGHT SENSOR
REAR ACCELERATION SENSOR
RETURN
RIGHT FRONT ACCELERATION SENSOR
RIGHT FRONT ACCELERATION WHEEL SENSOR
RIGHT FRONT DAMPER VALVE ACTUATOR
RIGHT FRONT HEIGHT SENSOR
RIGHT REAR ACTUATOR VALVE ACTUATOR
RIGHT REAR HEIGHT SENSOR
SENSOR
SIGNAL
TAN/DK BLU WIRE
TAN/DK GRN WIRE
TAN/GRN WIRE
TAN/ORG WIRE
TAN/VIO WIRE
TAN/YEL WIRE
VALVE
YEL WIRE
YEL/BLU WIRE
YEL/DK BLU WIRE
YEL/DK GRN WIRE
YEL/ORG WIRE
YEL/TAN WIRE
YEL/VIO WIRE
Go to component -> Electronic air suspension circuit (2 of 2) -> REAR ACCELERATION SENSOR
