Jeep Wagoneer WS (2021-2024) premium base wiring diagram
This page shows the only wiring diagram for the component.premium base, which is found in the car Jeep Wagoneer WS (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
premium base wiring diagram (1 of 1)
BLK WIRE
BRAKE PROVISION MODULE
BRAKE SIG 1
BRAKE SYSTEM CONTROL MODULE
CHMSL LAMP
DK GRN/WHT WIRE
DRV PARK LAMP
DRV STOP LAMP
DRV STOP/TURN LAMP DRV STOP LAMP
DRV TURN LAMP
FAULT SENSE SIG
GRN WIRE
HAZARD SW SENSE
HEADLAMP SWITCH
HEADLAMP/FOG LAMP SW SIG
LEFT LICENSE LAMP
LEFT LIFTGATE TAIL LAMP ASSEMBLY
LEFT TAIL LAMP ASSEMBLY
MUX SIG
PREMIUM
PREMIUM BASE
RIGHT LICENSE LAMP
RIGHT LIFTGATE TAIL LAMP ASSEMBLY
RIGHT TAIL LAMP ASSEMBLY
RTN
UPPER BANK SWITCH
WHT WIRE
WHT/BRN WIRE
WHT/DK BLU WIRE
WHT/DK GRN WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/ORG WIRE
WHT/TAN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> PREMIUM BASE
