Jeep Wagoneer WS (2021-2024) open sig Wiring diagram
This page shows the only wiring diagram for the component.open sig, which is found in the car Jeep Wagoneer WS (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram open sig (1 of 1)
BLK WIRE
BLU WIRE
BRN/YEL WIRE
CLS SIG
FSD B (+) CLS SIG
FUSE 20
HOT AT ALL TIMES
INTERIOR POWER DISTRIBUTION CENTER ASSEMBLY
LAMP DRV
OPEN SIG
OPN SIG
ORG/BLU WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/TAN WIRE
ORG/VIO WIRE
ORG/YEL WIRE
OVERHEAD CONSOLE MODULE
RED WIRE
RTN
SUNROOF MOTOR (REAR OF SUNROOF)
SUNROOF SHADE MOTOR
VENT SIG
VIO WIRE
WHT/GRY WIRE
YEL WIRE
Go to component -> Overhead console circuit -> OPEN SIG
