Jeep Wagoneer WS (2021-2024) motor generator unit module Wiring diagram
This page shows the only wiring diagram for the component.motor generator unit module, which is found in the car Jeep Wagoneer WS (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram motor generator unit module (1 of 1)
BATTERY PACK CONTROL MODULE
BLU WIRE
BLU/TAN WIRE
BRN/TAN WIRE
BRN/WHT WIRE
CAN FD (-)
CENTRAL ADAS DECISION LOW MODULE (RIGHT SIDE OF LUGGAGE COMPT)
DK BLU/TAN WIRE
DK BLU/WHT WIRE
DK GRN/TAN WIRE
DRIVETRAIN CONTROL MODULE
EARLY PRODUCTION
ELECTRONIC LIMITED SLIP DIFFERENTIAL MODULE
ETHERNET
GRN WIRE
GRN/TAN WIRE
GRY/TAN WIRE
KEYLESS IGNITION MODE MODULE
LATE PRODUCTION
MOTOR GENERATOR UNIT MODULE
ORG/TAN WIRE
PRIVATE
PRIVATE CAN FD -
RADIO FREQ HUB MODULE
SECURITY K LINE
TAN WIRE
VIO/TAN WIRE
WHT WIRE
WHT/BRN WIRE
WHT/DK BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Computer data lines circuit (3 of 11) -> MOTOR GENERATOR UNIT MODULE
