Jeep Wagoneer WS (2021-2024) left seat back video screen module Wiring diagram
This page shows the only wiring diagram for the component.left seat back video screen module, which is found in the car Jeep Wagoneer WS (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left seat back video screen module (1 of 1)
BLK WIRE
CENTER STACK SCREEN DISPLAY
DRIVER DOOR HANDLE LAMP
DRIVER DOOR LATCH
DRIVER DOOR MODULE
DRIVER MEMORY SWITCH
FRONT PASSENGER DISPLAY MODULE
FRONT PASSENGER MEDIA HUB DISPLAY PORT
LEFT FRONT DOOR BIN MODULE
LEFT FRONT DOOR SPEAKER MODULE
LEFT FRONT DOOR SPEAR 1 MODULE
LEFT FRONT DOOR SPEAR 2 MODULE
LEFT REAR DOOR BIN MODULE
LEFT REAR DOOR HANDLE LAMP
LEFT REAR DOOR SPEAKER LAMP
LEFT REAR DOOR SPEAR 1 MODULE
LEFT REAR DOOR SPEAR 2 MODULE
LEFT REAR DOOR TRIM PADDLE LAMP
LEFT REAR POWER WINDOW SWITCH
LEFT SEAT BACK VIDEO SCREEN MODULE
MEDIA PORT
RADIO
RADIO, AMPLIFIER
REAR DISPLAY CONVENIENCE, COMFORT MODULE
RIGHT SEAT BACK VIDEO SCREEN MODULE
VIDEO ROUTING MODULE
Go to component -> Ground distribution circuit (5 of 8) -> LEFT SEAT BACK VIDEO SCREEN MODULE
