Jeep Wagoneer WS (2021-2024) headlamp/ fog lamp sw sig Wiring diagram
This page shows the only wiring diagram for the component.headlamp/ fog lamp sw sig, which is found in the car Jeep Wagoneer WS (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlamp/ fog lamp sw sig (1 of 1)
BLK WIRE
BODY CONTROL MODULE
BRAKE SYSTEM CONTROL MODULE
CAN FD (-)
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/BLU WIRE
DK GRN/GRN WIRE
DK GRN/GRY WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
EPB IND SIG
FOG LP CTRL
FUSE 23
FUSE 32
FUSE 36
FUSE 54
FUSE 68
FUSED B (+)
FUSED B (+) LAMP DRIVER
FUSED IGN
GRY/TAN WIRE
HEADLAMP SWITCH
HEADLAMP/ FOG LAMP SW SIG
HOT AT ALL TIMES
HOT W/ RUN/START 1 RELAY ENERGIZED
INTERIOR POWER DISTRIBUTION CENTER ASSEMBLY
LEFT FRONT FOG LAMP
MUX SIGNAL
ORG/GRY WIRE
ORG/TAN WIRE
PARKING BRAKE SWITCH
PNK/VIO WIRE
POSITION SIG 1
POSITION SIG 2
POSITION SIG 3
POSITION SIG 4
POSITION SIG 5
POSITION SIG 6
POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RED/GRN WIRE
RED/TAN WIRE
RETURN
RIGHT FRONT FOG LAMP
SMART LIGHTING MODULE
SMART LIGHTING MODULE LEFT FRONT LAMP ASSEMBLY
TAN WIRE
VIO WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/YEL WIRE
Go to component -> Headlights circuit -> HEADLAMP/ FOG LAMP SW SIG
