Jeep Wagoneer WS (2021-2024) drv left stop/ turn lamp Wiring diagram
This page shows the only wiring diagram for the component.drv left stop/ turn lamp, which is found in the car Jeep Wagoneer WS (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv left stop/ turn lamp (1 of 1)
8 VOLT SPLY
BASE
BLK WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRAKE PROVISION MODULE
BRAKE SIG 1
BRN WIRE
BRN/YEL WIRE
CAN C 1 (+)
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/BLK WIRE
DK GRN/BLU WIRE
DK GRN/GRN WIRE
DK GRN/ORG WIRE
DK GRN/PNK WIRE
DK GRN/TAN WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DRV BACKUP LAMP
DRV LAMP
DRV LEFT STOP/ TURN LAMP
DRV PARK LAMP
DRV RIGHT STOP/ TURN LAMP
ELECTRIC BRAKE POWER SPLY
EXTERIOR LAMPS CIRCUIT
FUSE 21
FUSE 35
FUSE 37
FUSE 57
FUSE 63
FUSED B (+)
FUSED B (+) FUSED IGN
HOT AT ALL TIMES
HOT W/ RUN/START 2 RELAY ENERGIZED
INTEGRATED TRAILER BRAKE SWITCH
INTERIOR POWER DISTRIBUTION CENTER ASSEMBLY
ORG/GRY WIRE
PNK/GRN WIRE
PREMIUM
REAR POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RED/YEL WIRE
RTN
SIG
SIG (1)
SIG (2)
TAN/RED WIRE
TRAILER TOW 7 WAY WIRING
TRAILER TOW BRAKE SW DECREASE
TRAILER TOW BRAKE SW INCREASE
TRAILER TOW MODULE (RIGHT SIDE OF REAR BUMPER)
WHT WIRE
YEL WIRE
Go to component -> Trailer tow circuit -> DRV LEFT STOP/ TURN LAMP
