Jeep Wagoneer WS (2021-2024) driver up/down seat lumbar motor Wiring diagram
This page shows the only wiring diagram for the component.driver up/down seat lumbar motor, which is found in the car Jeep Wagoneer WS (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver up/down seat lumbar motor (1 of 1)
BLK WIRE
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DRIVER FORWARD/REARWARD SEAT LUMBAR MOTOR
DRIVER HORIZONTAL SEAT ADJUSTER MOTOR
DRIVER LUMBAR SEAT ADJUSTER SWITCH
DRIVER MEMORY SEAT MODULE (UNDER DRIVER'S SEAT)
DRIVER RECLINER SEAT ADJUSTER MOTOR
DRIVER UP/DOWN SEAT LUMBAR MOTOR
FRONT DRIVER VERTICAL SEAT ADJUSTER MOTOR
FUSE 30
FUSE 86
FUSED B (+)
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/DK GRN WIRE
GRN/GRY WIRE
GRN/ORG WIRE
GRN/TAN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
MOTOR (FORWARD)
MOTOR (IN)
MOTOR (OUT)
MOTOR (REARWARD)
MOTOR + UP
MOTOR DOWN
REAR DRIVER VERTICAL SEAT ADJUSTER MOTOR
REAR POWER DISTRIBUTION CENTER ASSEMBLY
RED/ORG WIRE
RED/VIO WIRE
WHT WIRE
Go to component -> Driver power seat circuit -> DRIVER UP/DOWN SEAT LUMBAR MOTOR
