Jeep Wagoneer WS (2021-2024) center stack screen module Wiring diagram
This page shows the only wiring diagram for the component.center stack screen module, which is found in the car Jeep Wagoneer WS (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center stack screen module (1 of 1)
AC VOLT LINE 1
AC VOLT LINE 2
AC VOLT LINE 3
BLK WIRE
BODY CONTROL MODULE
CENTER STACK SCREEN MODULE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR 1
FROM FUSE 20 (DIAGRAM 1 OF 8)
FRONT INTEGRATED CENTER STACK MODULE
FRONT PASSENGER DISPLAY MODULE
FSD B(+)
FUSE 32
FUSE 45
FUSE 49
FUSE 50
FUSE 63
FUSE 64
GLOBAL TELEMATIC BOX MODULE
GRN WIRE
GRN/BLU WIRE
GRN/DK BLU WIRE
GRN/ORG WIRE
GRY/RED WIRE
HUMIDITY RAIN LIGHT MODULE
HVAC MODULE
INV SW SIG
INVERTER MODULE
K LINE
KEYLESS IGNITION NODE MODULE
LIN BUS
MEDIA PORT
OCCUPANT RESTRAINT MODULE
ORG/VIO WIRE
PARKING BRAKE SWITCH
POSI SIG
POWER OUTLET
RADIO FREQUENCY HUB MODULE
REAR USB CHARGING CONSOLE PORT
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/TAN WIRE
RED/VIO WIRE
SECURITY
STEERING COLUMN CONTROL MODULE
TO RUN/ ACCESSORY 1 RELAY (DIAGRAM 7 OF 8)
UPPER BANK SWITCH
VIO/BLU WIRE
WHT/GRN WIRE
WIRELESS CHARGING PAD MODULE
Go to component -> Power distribution circuit (2 of 8) -> CENTER STACK SCREEN MODULE
