Jeep Wagoneer WS (2021-2024) center screen stack module Wiring diagram
This page shows the only wiring diagram for the component.center screen stack module, which is found in the car Jeep Wagoneer WS (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center screen stack module (1 of 1)
BLK WIRE
CAMERA CABLE
CENTER SCREEN STACK MODULE
FRONT AUXILIARY VIDEO PORT
FUSE 13
FUSE 53
FUSE 63
FUSED B (+)
FUSED IGN
GROUND
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ RUN/ ACCESSORY 1 RELAY ENERGIZED
INTERIOR CAMERA MODULE
INTERIOR POWER DISTRIBUTION CENTER ASSEMBLY
LAMP DRIVER
LIN BUS
ORG/ WIRE
ORG/GRY WIRE
PNK/YEL WIRE
PVT ETHERNET (+)
RADIO
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT SCREEN SEATBACK VIDEO MODULE
SIGNAL
VIDEO CABLE
VIDEO LVDS DATA 0 (-)
WHT WIRE
YEL WIRE
Go to component -> Rear seat entertainment circuit (2 of 2) -> CENTER SCREEN STACK MODULE
