Jeep Renegade I facelift (2018-2024) serial data gateway module Wiring diagram
This page shows the only wiring diagram for the component.serial data gateway module, which is found in the car Jeep Renegade I facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram serial data gateway module (1 of 1)
BLK WIRE
BODY CONTROL MODULE
CARGO LAMP RELAY
CENTER HIGH MOUNTED STOP LAMP
COLLISION ALERT INDICATORS
DATA LINK CONNECTOR
DOME LAMP SWITCH
FRONT DIFFERENTIAL LOCK ACTUATOR LOW CONTROL RELAY
FRONT DOME/ READING LAMPS
HEADLAMP SWITCH
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSIDE REAR VIEW MIRROR
INSTRUMENT CLUSTER LOGIC
LEFT CARGO LAMP
LEFT SUNSHADE
NCA WIRE
PASSENGER AIR BAG DISABLED INDICATOR
PASSENGER PRESENCE MODULE
PASSENGER SEAT BELT BUCKLE
PASSENGER SEAT BELT TENSION SENSOR
REAR DEFOGGER GRID
REAR DOME READING LAMPS
RIGHT CARGO LAMP
RIGHT SUNSHADE
SERIAL DATA GATEWAY MODULE
SIG GND
TRANSFER CASE CONTROL MODULE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK
W/ ONSTAR
WHT WIRE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
Go to component -> Ground distribution circuit (3 of 5) -> SERIAL DATA GATEWAY MODULE
