Jeep Renegade I facelift (2018-2024) de-icer ctrl Wiring diagram
This page shows the only wiring diagram for the component.de-icer ctrl, which is found in the car Jeep Renegade I facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram de-icer ctrl (1 of 1)
BLK WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
BRN/BLK WIRE
BRN/DK BLU WIRE
BRN/WHT WIRE
CAN IHS (-)
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DE-ICER CTRL
DEFOGGER RLY CTRL
DK BLU WIRE
DK BLU/GRN WIRE
DRIVER OUTSIDE REAR- VIEW MIRROR
ELECTRIC HEATED BACKLITE
ELECTRIC WINDSHIELD WIPER
FRONT WINDSHIELD DEFROST (SUPPLY)
FUSE 23
FUSE 51
FUSE 88
FUSE 89
GRY WIRE
HEATED WINDSHIELD GRID
HOT AT ALL TIMES
HOT W/ IGNITION RUN 1 RELAY ENERGIZED
HVAC MODULE
MIRR HEATER DRIVER
PASSENGER OUTSIDE REAR VIEW MIRROR
POWER DISTRIBUTION CENTER ASSEMBLY
REAR WINDOW DEFOGGER CTRL OUT
REAR WINDOW DEFOGGER RELAY
RED WIRE
WHT WIRE
WHT/BRN WIRE
WHT/PNK WIRE
WINDSHIELD DE-ICER RELAY
YEL/GRY WIRE
Go to component -> Defoggers circuit -> DE-ICER CTRL
