2.4l, charging circuit for Jeep Liberty I (2001-2007)

ASD RLY GEN SRC ASD RLY INPUT ASD RLY CONTROL PCI BUS AUTO SHUT DOWN RELAY B(+) BATTERY BATTERY INDICATOR BLK WIRE BRN WIRE BRN/DK GRN WIRE BRN/RED WIRE BRN/WHT WIRE DK GRN WIRE FUSE 26 FUSED IGNITION FUSIBLE LINK (10 GA- GENERATOR GRY WIRE HOT IN RUN OR START INPUT INSTRUMENT CLUSTER JUNCTION BLOCK (LEFT SIDE OF DASH) FUSE 13 NCA WIRE PCI BUS PNK WIRE PNK/GRY WIRE PNK/LT GRN WIRE POWER DISTRIBUTION FUSE 6 CENTER (LEFT SIDE OF ENGINE COMPT) POWERTRAIN CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) RED WIRE STARTER MOTOR WHT WIRE WHT/VIO WIRE
