Anti-lock brakes circuit for Jeep Liberty I (2001-2007)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 FUSED B(+) ABS WARNING IND CONTROL ABS WARNING INDICATOR BLK WIRE BLK/DK GRN WIRE BLK/LT BLU WIRE BODY CONTROL MODULE (INTEGRAL WITH OUTBOARD JUNCTION BLOCK) BRAKE LAMP SW OUT BRAKE LAMP SWITCH (ABOVE BRAKE PEDAL, ON BRACKET) BRAKE SW SENSE COMPUTER DATA LINES SYSTEM CONTROLLER ANTI-LOCK BRAKE (LEFT SIDE OF ENGINE COMPT) DIESEL DIESEL DK GRN WIRE DK GRN/DK BLU WIRE DK GRN/LT BLU WIRE DK GRN/LT GRN WIRE DK GRN/TAN WIRE DK GRN/VIO WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE ENGINE CONTROL MODULE FUSE 13 FUSE 25 FUSE 38 FUSE IGN SW (RUN) FUSED B(+) RF WHL SPD SIG GAS GROUND GRY WIRE HOT AT ALL TIMES HOT IN HOT IN RUN OR START INSTRUMENT CLUSTER JUNCTION BLOCK (LEFT SIDE OF DASH) FUSE 12 LEFT FRONT WHEEL SPEED SENSOR LF WHL SPD SIG GROUND LT GRN WIRE PCI BUS PNK WIRE PNK/LT GRN WIRE PNK/TAN WIRE POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT) FUSE 4 POWERTRAIN CONTROL MODULE REAR WHEEL SPEED SENSOR REAR WHL SPD SIG RED WIRE RED/DK GRN WIRE RIGHT FRONT WHEEL SPEED SENSOR RUN WIRE RUN/START SCI TRANSMIT PCI BUS CAN C BUS (+) CAN C BUS (-) SECONDARY BRAKE SW SHIFT INTERLOCK SYSTEM TAN WIRE TAN/RED WIRE VEHICLE SPEED SIG WHT WIRE WHT/GRY WIRE WHT/LT GRN WIRE WHT/TAN WIRE WHT/VIO WIRE
