Wiper/washer circuit for Jeep Grand Cherokee WL (2021-2024)

Wiper/washer circuit (1 of 2)

Grand Cherokee Jeep WL (2021-2024): Wiper/washer circuit (1 of 2)

Get access

BLK WIRE BODY CONTROL MODULE (RIGHT END OF DASH) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/ORG WIRE BRN/TAN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CAMERA WASHER MOTOR CAMERA WASHER RELAY CAN FD (-) COMPUTER DATA LINES SYSTEM CTRL FRONT WASHER FLUID LEVEL SENSOR FRONT WIPER MOTOR (LEFT SIDE OF PLENUM) FUSE 103 FUSE 18 FUSE 63 GRN/VIO WIRE GRY/TAN WIRE HEADLAMP WASHER RELAY HOT AT ALL TIMES LIN BUS LVL SW SNS PARK SW SENS PARK SW SIG POWER DISTRIBUTION CENTER ASSEMBLY RETURN RLY OUTPUT TAN WIRE WHT/VIO WIRE WIPER HIGH/LOW RELAY WIPER ON/OFF RELAY

Wiper/washer circuit (2 of 2)

Grand Cherokee Jeep WL (2021-2024): Wiper/washer circuit (2 of 2)

Get access

BASE BLK WIRE BLK/GRY WIRE BRN WIRE BRN/GRN WIRE BRN/ORG WIRE BRN/YEL WIRE CAN FD (-) CLUSTER COMPUTER DATA LINES SYSTEM CTRL FUSE 33 FUSED B (+) GRY/TAN WIRE HEADLAMP WASHER MOTOR HOT AT ALL TIMES HUMIDITY RAIN LIGHT MODULE INTERIOR POWER DISTRIBUTION CENTER ASSEMBLY LIN BUS PARK SW SIG PREMIUM REAR WIPER MOTOR RED/YEL WIRE REVERSIBLE WINDSHIELD WASHER PUMP RLY OUTPUT TAN WIRE WHT/VIO WIRE
