Heated seats circuit, w/o ventilation w/ third row seat for Jeep Grand Cherokee WL (2021-2024)
Heated seats circuit, w/o ventilation w/ third row seat (1 of 2)
BLK WIRE
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DK GRN/GRN WIRE
FRONT INTEGRATED CENTER STACK MODULE
FUSE 32
FUSE 62
FUSE 81
FUSE 82
FUSED IGN
GRN WIRE
GRN/DK BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RUN 1 RELAY ENERGIZED
HOT W/ IGNITION RUN 2 RELAY ENERGIZED
INTERIOR POWER DISTRIBUTION CENTER ASSEMBLY
LEFT REAR COMFORT SEAT MODULE
LEFT REAR SEAT BACK HEATER
LEFT REAR SEAT CUSHION HEATER
LIN BUS
PNK/BRN WIRE
PNK/VIO WIRE
PNK/YEL WIRE
POWER SPLY
REAR POWER DISTRIBUTION CENTER ASSEMBLY
RED/TAN WIRE
RTN
SENS RTN
TAN/GRN WIRE
TEMP SIG
WHT WIRE
WHT/VIO WIRE
Heated seats circuit, w/o ventilation w/ third row seat (2 of 2)
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK GRN/GRN WIRE
FUSED IGN
GRN WIRE
GRN/DK BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/YEL WIRE
LIN BUS
PNK/BRN WIRE
PNK/YEL WIRE
POWER SPLY
REAR HEATED SEAT SWITCH
RIGHT REAR COMFORT SEAT MODULE
RIGHT REAR SEAT BACK HEATER
RIGHT REAR SEAT CUSHION HEATER
RTN
SENS RTN
TAN/GRN WIRE
TEMP SIG
WHT/DK GRN WIRE
WHT/TAN WIRE
WHT/VIO WIRE
