Wiring diagram engine performance 3.6l flex fuel, engine vibration reduction circuit for Jeep Grand Cherokee WL (2021-2024)
Wiring diagram engine performance 3.6l flex fuel, engine vibration reduction circuit
BLK WIRE
CAN FD (-)
COMPUTER DATA LINES SYSTEM
DK BLU/GRY WIRE
DK BLU/ORG WIRE
FUSE 23
FUSE 67
FUSED IGN
GRY/TAN WIRE
HOT W/ RUN/START 1 RELAY ENERGIZED
LEFT ENGINE MOUNT SOLENOID
LSD CTRL
PNK/GRN WIRE
PNK/VIO WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
POWERTRAIN CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT)
RIGHT ENGINE MOUNT SOLENOID
TAN WIRE
