Jeep Grand Cherokee WL (2021-2024) stow fold module Wiring diagrams
This page contains all the electrical diagrams for the component. stow fold module, in which he is found in the car Jeep Grand Cherokee WL (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram stow fold module (1 of 2)
AIR SUSPENSION CONTROL MODULE
BASE
BLU/TAN WIRE
BRN/TAN WIRE
BRN/YEL WIRE
CAN FD (-)
CAN IHS (-)
CAN IHS (-) AT
DK BLU/TAN WIRE
DK BLU/WHT WIRE
DRIVER DOOR MODULE
DRIVER SEAT MASSAGE MODULE
DRIVER SEAT MEMORY MODULE
DRIVER WINDOW/DOOR LOCK SWITCH
ETHERNET
FRONT INTEGRATED CENTER STACK MODULE
FRONT PASSENGER DISPLAY MODULE
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRY/TAN WIRE
INTRUSION SENSOR TRANSMITTER
LIN BUS
LONG WHEEL BASE
PREMIUM
PVT ETHERNET (+)
RADIO
SCREEN CENTER STACK DISPLAY
SHIELD
SHORT WHEEL BASE
STOW FOLD MODULE
TAN WIRE
TRAILER TOW MODULE
VIDEO ROUTING MODULE
VIO/TAN WIRE
W/ AIR SUSPENSION
W/ REAR SEAT ENTERTAINMENT
W/O AIR SUSPENSION
WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Computer data lines circuit (6 of 10) -> STOW FOLD MODULE
Wiring diagram stow fold module (2 of 2)
3.6L
AIR SUSPENSION CONTROL MODULE
BLK WIRE
BLK/GRY WIRE
BLK/YEL WIRE
CHMSL LAMP
ELECTRIC HEATED BACKLITE
ELECTRONIC DIFFERENTIAL LIMITED SLIP MODULE
FUEL PUMP CONTROL MODULE
IGNITION COIL 1
IGNITION COIL 3
IGNITION COIL 5
INTERIOR CAMERA MODULE
LEFT LICENSE LAMP
LEFT LIFTGATE LAMP
POWER LIFTGATE HANDLE SWITCH 1
RADIO FREQ HUB MODULE
REAR WIPER MOTOR
RIGHT LICENSE LAMP
RIGHT LIFTGATE TAIL LAMP ASSEMBLY
RIGHT REAR MID RANGE RADAR
RIGHT TAIL LAMP ASSEMBLY
STOW FOLD MODULE
TOP OF ENGINE)
VVL SOLENOID 1/1
VVL SOLENOID 1/2
VVT EXHAUST SOLENOID 1/2
VVT INTAKE SOLENOID 1/2
Go to component -> Ground distribution circuit (7 of 8) -> STOW FOLD MODULE
