Jeep Grand Cherokee WK2 (2010-2013) electronic overhead module Wiring diagram
This page shows the only wiring diagram for the component.electronic overhead module, which is found in the car Jeep Grand Cherokee WK2 (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic overhead module (1 of 1)
BATT FD 6
BLK WIRE
CIRCUIT BOARD
ELECTRONIC OVERHEAD MODULE
HOT AT ALL TIMES
IGN
IGN RUN ACC
NCA WIRE
ORG/BLK WIRE
ORG/DK GRN WIRE
ORG/GRY WIRE
ORG/LT BLU WIRE
ORG/LT GRN WIRE
ORG/TAN WIRE
ORG/VIO WIRE
ORG/YEL WIRE
PNK/YEL WIRE
RED WIRE
RUN WIRE
SHADE CLOSE
SHADE OPEN
SUNRF DGNSTC LINE
SUNRF PWR CLS (+)
SUNRF PWR OPN (+)
SUNRF SWD RTN
SUNRF VENT (+)
SUNROOF MOTOR
SUNROOF SHADE MOTOR
TOTALLY INTEGRATED POWER MODULE
Go to component -> Power top/sunroof circuit, dual pane -> ELECTRONIC OVERHEAD MODULE
