Jeep Gladiator JT (2019-2023) vvl solenoid 2/1 Wiring diagram
This page shows the only wiring diagram for the component.vvl solenoid 2/1, which is found in the car Jeep Gladiator JT (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vvl solenoid 2/1 (1 of 1)
3.6L
AFTERMARKET ELECTRIC BRAKE JUMPER MODULE
BLK WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/WHT WIRE
CABIN HEATER
CAMSHAFT POSITION SOLENOID 2/2
CENTER CONSOLE LAMP
COMFORT SEAT STEERING WHEEL MODULE
COMPASS MODULE
CUP HOLDER LAMP
ELECTRONIC SHIFT MODULE
EXHAUST VVT SOLENOID 2/2
FRONT CUP HOLDER LAMP
HVAC MODULE
IGNITION COIL 2
IGNITION COIL 4
IGNITION COIL 6
INTAKE VVT SOLENOID 2/1
INTEGRATED CENTER STACK SWITCH BANK MODULE
MEDIA PORT
PREMIUM
RADIO
RADIO, AMPLIFIER
REAR MEDIA PORT
RIGHT END OF DASH)
RIGHT FRONT FOOTWELL LAMP
SECURITY GATEWAY MODULE
STAR CAN C IP CONNECTOR
STAR CAN IHS IP CONNECTOR
VVL SOLENOID 2/1
VVL SOLENOID 2/2
Go to component -> Ground distribution circuit (5 of 5) -> VVL SOLENOID 2/1
