Jeep Gladiator JT (2019-2023) rf passive entry handle sw sens Wiring diagram
This page shows the only wiring diagram for the component.rf passive entry handle sw sens, which is found in the car Jeep Gladiator JT (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf passive entry handle sw sens (1 of 1)
3.6L
ANT UHF ANT SIG
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BODY CONTROL MODULE
CAN C (+)
CLUTCH INTERLOCK
CLUTCH INTERLOCK SIG
CLUTCH INTERLOCK ST CTRL CAN C (+)
CLUTCH INTERLOCK SWITCH
COMPUTER DATA LINES SYSTEM
CTRL OUT
DK BLU WIRE
DK GRN/YEL WIRE
FSD B(+)
FUSE 10
FUSED B (+)
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
GRY/ORG WIRE
GRY/TAN WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
IGN RUN/START
IGN RUN/START CTRL OUT
IGN SW POS SIG
KEYLESS IGNITION NODE MODULE
LEFT FRONT EXTERIOR DOOR HANDLE SWITCH
LF PASSIVE ENTRY HANDLE SW RTN
LF PASSIVE ENTRY HANDLE SW SENS
PASSIVE ENTRY ANT 1 RTN
PASSIVE ENTRY ANT 1 SIG
PASSIVE ENTRY ANT 2 RTN
PASSIVE ENTRY ANT 2 SIG
PASSIVE ENTRY ANT 3 RTN
PASSIVE ENTRY ANT 3 SIG
PASSIVE ENTRY ANT 4 RTN
PASSIVE ENTRY ANT 4 SIG
PASSIVE ENTRY ANTENNA 1
PASSIVE ENTRY ANTENNA 2
PASSIVE ENTRY ANTENNA 3
PASSIVE ENTRY ANTENNA 4
PNK/WHT WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
POWERTRAIN CONTROL MODULE
RADIO FREQUENCY HUB MODULE (CENTER REAR OF CAB)
RED/BRN WIRE
REMOTE START ANTENNA
RF PASSIVE ENTRY HANDLE SW RTN
RF PASSIVE ENTRY HANDLE SW SENS
RIGHT FRONT EXTERIOR DOOR HANDLE SWITCH
SECURITY K LINE COMM
ST CTRL
TRS PARK SIG
VIO/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/DK BLU WIRE
YEL/VIO WIRE
Go to component -> Passive entry circuit -> RF PASSIVE ENTRY HANDLE SW SENS
