Jeep Gladiator JT (2019-2023) particulate matter sensor Wiring diagram
This page shows the only wiring diagram for the component.particulate matter sensor, which is found in the car Jeep Gladiator JT (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram particulate matter sensor (1 of 1)
3.6L 3.0L TURBO DIESEL
AUTOMATIC SWAY BAR MODULE
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BODY CONTROL MODULE
BOOST PRESSURE SERVO MOTOR
CARGO LAMP 2
CIRCUIT BOARD
DEF LINE PRESSURE HEATER
DEF QUALITY SENSOR
DEF TANK ASSEMBLY
FUEL PUMP CONTROL MODULE
GLOW PLUG MODULE
HEATER CONTROL MODULE
INTELLIGENT BATTERY SENSOR
LEFT FRONT FOG LAMP
MASS AIR FLOW SENSOR
NOX 1/1 SENSOR
NOX 1/2 SENSOR
OCCUPANT RESTRAINT CONTROLLER MODULE
OXYGEN SENSOR 1/1
OXYGEN SENSOR 1/2
OXYGEN SENSOR 2/1
OXYGEN SENSOR 2/2
PARTICULATE MATTER SENSOR
POWER DISTRIBUTION CENTER ASSEMBLY
POWER STEERING PUMP MOTOR
POWERTRAIN CONTROL MODULE
RADIO FREQUENCY HUB MODULE
REAR DOME LAMP
RIGHT DRL LAMP
RIGHT FRONT FOG LAMP
STAR CAN IHS BODY CONNECTOR
TIRE PRESSURE MODULE
TRANSMISSION CONTROL MODULE
W/ PARKING ASSIST SYSTEM
W/O PARKING ASSIST SYSTEM
Go to component -> Ground distribution circuit (2 of 5) -> PARTICULATE MATTER SENSOR
