Jeep Gladiator JT (2019-2023) off road bank switch 2 Wiring diagrams
This page contains all the electrical diagrams for the component. off road bank switch 2, in which he is found in the car Jeep Gladiator JT (2019-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram off road bank switch 2 (1 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR
CLUSTER
CONSOLE CIGAR LIGHTER
DATA LINK CONNECTOR 1
DRIVER ASSISTANT SYSTEM MODULE
DRIVER BLIND SPOT INDICATOR LAMP
DRIVER DOOR HANDLE LAMP
DRIVER DOOR LOCK SWITCH
DRIVER GLASS HEATER
DRIVER MIRROR TURN INDICATOR LAMP
DRIVER OUTSIDE REAR- VIEW MIRROR
FRONT WINDOW SWITCH
HEADLAMP LEVELING MODULE
HEADLAMP SWITCH
IN-CAR TEMPERATURE SENSOR
INSIDE REAR VIEW MIRROR
INVERTER MODULE
INVERTER SWITCH
KEYLESS IGNITION NODE MODULE
LEFT FRONT FOOTWELL LAMP
LEFT VANITY LAMP
MIRROR SWITCH
OFF ROAD BANK SWITCH 2
OVERHEAD CONSOLE SWITCH
PASSENGER BLIND SPOT INDICATOR LAMP
PASSENGER DOOR HANDLE LAMP
PASSENGER DOOR LOCK SWITCH
PASSENGER GLASS HEATER
PASSENGER MIRROR TURN INDICATOR LAMP
PASSENGER OUTSIDE REAR VIEW MIRROR
PREMIUM
RIGHT END OF DASH)
RIGHT VANITY LAMP
SEAT BELT REMINDER INDICATOR
STEERING COLUMN CONTROL MODULE
STEERING COLUMN LOCK MODULE
UPPER BANK SWITCH
Go to component -> Ground distribution circuit (3 of 5) -> OFF ROAD BANK SWITCH 2
Wiring diagram off road bank switch 2 (2 of 2)
ANTI-LOCK BRAKES MODULE
AUX 2 RLY CTRL SIG
AUX 3 RLY CTRL SIG
AUX 4 RLY CTRL SIG
AUXILIARY 1 RELAY
AUXILIARY 2 RELAY
AUXILIARY 3 RELAY
AUXILIARY 4 RELAY
BLK/GRY WIRE
BLK/YEL WIRE
BODY CONTROL MODULE
BRAKE/
BRN/GRY WIRE
BRN/ORG WIRE
BRN/VIO WIRE
BRN/WHT WIRE
DK BLU/PNK WIRE
DK GRN/WHT WIRE
FROM HORN RELAY (DIAGRAM 4 OF 5)
FROM POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 2 OF 5)
FSD B (+) AUX 1 RLY CTRL SIG
FSD B(+)
FUSE 103
FUSE 108
FUSE 27
FUSE 92
FUSE 93
FUSE 98
GRN/PNK WIRE
IGN (RUN)
INTELLIGENT BATTERY SENSOR
LIN BUS CBC 1
LIN BUS CBC 2
OFF ROAD BANK SWITCH 2
ORG/ WIRE
ORG/PNK WIRE
OUT
PNK/ORG WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
REAR WINDOW DEFOGGER RELAY
RED/VIO WIRE
RED/WHT WIRE
RLY 1 OUT
RLY 2 OUT
RLY 3 OUT
RLY 4 OUT
SIGNAL 1
TAN/PNK WIRE
UPFITTER ACCESSORIES
UPFITTER ACCESSORIES 1
UPFITTER ACCESSORIES 2
UPPER BANK SWITCH
WIPER ON/ OFF RELAY
Go to component -> Power distribution circuit (5 of 5) -> OFF ROAD BANK SWITCH 2
