Car Wiring Diagrams for Telematics circuit for Jeep Compass II facelift (2020-2024)

ANTENNA BLK WIRE BLK/VIO WIRE BODY CONTROL MODULE BRN WIRE BRN/WHT WIRE CAN C (+) CAN C (+) AT CAN C (+) AT EMERGENCY SW RTN CAN IHS (-) AT CELL ANTENNA CELLULAR CELLULAR ANTENNA SIG CLUSTER COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE EMERGENCY BACKLIGHT CTRL EMERGENCY COMM BUTTON SPLY EMERGENCY SW LED 1 SPLY EMERGENCY SW LED 2 SPLY EMERGENCY SW RTN FUSE 36 FUSED B (+) EMERGENCY COMM BUTTON SPLY GLOBAL TELEMATIC BOX MODULE (ABOVE RADIO) GPS ANTENNA SIG GPS/SATELLITE GPS/SATELLITE RADIO ANTENNA SIG GROUND GRY WIRE HOT AT ALL TIMES INSIDE REAR VIEW MIRROR ORG/ WIRE ORG/BLK WIRE RADIO RADIO ANTENNA RADIO GPS ANTENNA RED WIRE SIG USB CABLE WHT WIRE YEL WIRE YEL/VIO WIRE
