Jeep Compass II facelift (2020-2024) variable valve actuation solenoid 4 Wiring diagram
This page shows the only wiring diagram for the component.variable valve actuation solenoid 4, which is found in the car Jeep Compass II facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram variable valve actuation solenoid 4 (1 of 1)
5 VOLT SUPPLY
BRN WIRE
BRN/BLU WIRE
BRN/DK GRN WIRE
BRN/GRN WIRE
BRN/PNK WIRE
BRN/WHT WIRE
COIL CONTROL 1
DK BLU WIRE
DK BLU/BLU WIRE
DK BLU/DK GRN WIRE
DK BLU/GRN WIRE
DK BLU/PNK WIRE
DK BLU/TAN WIRE
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/PNK WIRE
ECT SIGNAL
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE OIL TEMPERATURE SENSOR
EOP SIGNAL
EOT SIGNAL
ETC MOTOR (+) HIGH SIDE CONTROL
ETC MOTOR (-) COIL CONTROL 2
GEN SENSE
HIGH SIDE CONTROL
INTAKE AIR TEMPERATURE SENSOR
KS 1 RETURN
KS 1 SIGNAL
LOW SIDE CONTROL
MAP SIGNAL
PNK/YEL WIRE
POWERTRAIN CONTROL MODULE
RED/VIO WIRE
SENSOR GROUND
STARTING/CHARGING SYSTEM
TAN/ORG WIRE
TAN/YEL WIRE
VARIABLE VALVE ACTUATION SOLENOID 1
VARIABLE VALVE ACTUATION SOLENOID 2
VARIABLE VALVE ACTUATION SOLENOID 3
VARIABLE VALVE ACTUATION SOLENOID 4
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/PNK WIRE
YEL/PNK WIRE
Go to component -> Wiring diagram engine performance 2.4l (6 of 6) -> VARIABLE VALVE ACTUATION SOLENOID 4
