Jeep Compass II facelift (2020-2024) driver lumbar motor pnk Wiring diagram
This page shows the only wiring diagram for the component.driver lumbar motor pnk, which is found in the car Jeep Compass II facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver lumbar motor pnk (1 of 1)
BLK WIRE
BLK/GRY WIRE
BODY CONTROL MODULE
CIRCUIT BOARD
DRIVER LUMBAR
DRIVER LUMBAR MOTOR PNK WIRE
DRIVER LUMBAR SEAT ADJUSTER SWITCH
FUSE 2-6
FUSE 6
GRN WIRE
GRN/BRN WIRE
GRN/DK GRN WIRE
GRN/ORG WIRE
GRN/PNK WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GROUND
HOT AT ALL TIMES
LUMBAR DOWNWARD PASS
LUMBAR RLY FSD CTRL B (+)
LUMBAR UPWARD PASS
MOTOR
PASS SEAT LUMBAR IN DRV
PASS SEAT LUMBAR OUT DRV
PASSENGER LUMBAR SEAT ADJUSTER SWITCH
PASSENGER SEAT LUMBAR PUMP MOTOR
POWER DISTRIBUTION CENTER ASSEMBLY
POWER DISTRIBUTION SYSTEM
POWER SEAT RELAY
REAR POWER DISTRIBUTION CENTER ASSEMBLY
RED/GRN WIRE
RED/GRY WIRE
SEAT LUMBAR RELAY 2
VIO/RED WIRE
W/ START/STOP
W/O START/STOP
Go to component -> Passenger"s lumbar circuit -> DRIVER LUMBAR MOTOR PNK WIRE
