Jeep Compass II facelift (2020-2024) clutch position sensor Wiring diagram
This page shows the only wiring diagram for the component.clutch position sensor, which is found in the car Jeep Compass II facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram clutch position sensor (1 of 1)
ANT RTN 1 FR DRV PASSIVE ENTRY HNDL SW RTN
ANT RTN 2
ANT RTN 3
ANT RTN 4
ANT RTN 5
ANT SIG (2)
ANT SIG (5)
ANT SIG 1 FR DRV PASSIVE ENTRY HNDL SW SNS
ANT SIG 3
ANT SIG 4
ANT UHF ANT SIG
BLK WIRE
BODY CONTROL MODULE
BOTTOM OF LIFTGATE)
BRAKE SIGNAL 1
CAN C (+)
CLUTCH INTERLOCK SIG
CLUTCH POSITION SENSOR
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN/GRN WIRE
DK GRN/YEL WIRE
FR PASS PASSIVE ENTRY HNDL SW RTN
FR PASS PASSIVE ENTRY HNDL SW SNS
FRONT PASSENGER EXTERIOR DOOR HANDLE SWITCH
FSD B (+) IGN SW SENS
FUSE 53
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
GRY/DK GRN WIRE
GRY/GRN WIRE
GRY/ORG WIRE
GRY/TAN WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
IGN RUN/ST CTRL OUT
PASSIVE ENTRY ANTENNA 4
PASSIVE ENTRY ANTENNA 5
PNK/WHT WIRE
RADIO FREQUENCY HUB MODULE
RED WIRE
REMOTE START ANTENNA
SECURITY K LINE
VIO/BRN WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Passive entry circuit (1 of 2) -> CLUTCH POSITION SENSOR
