Jeep Compass II (2016-2022) w/ adaptive speed control Wiring diagram
This page shows the only wiring diagram for the component.w/ adaptive speed control, which is found in the car Jeep Compass II (2016-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ adaptive speed control (1 of 1)
BACKUP LAMP SWITCH
BASE PREMIUM
BLK WIRE
COMPUTER DATA LINES SYSTEM
FORWARD FACING CAMERA
FROM CIRCUIT BOARD (DIAGRAM 2 OF 6)
FROM POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 6 OF 6)
FUSE 51
FUSED B (+)
HEADLAMP SWITCH
HVAC MODULE
IGN SW
IGN SW SENSE
KEYLESS IGNITION NODE MODULE
OCCUPANT CLASSIFICATION MODULE
PNK/GRN WIRE
PREMIUM
RADIO FREQUENCY HUB MODULE
REAR VIDEO CAMERA
RED WIRE
RED/VIO WIRE
SECURITY K LIN COMMUNICATION
SENSE
STOP LAMP SWITCH
TERRAIN SWITCH BANK MODULE
TO FUSE 49 (DIAGRAM 4 OF 6)
TO POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 6 OF 6)
TRAILER TOW FUSE 5
TRAILER TOW FUSE 6
TRAILER TOW MODULE
VIO/BRN WIRE
W/ ADAPTIVE SPEED CONTROL
WHT/GRN WIRE
Go to component -> Power distribution circuit (3 of 6) -> W/ ADAPTIVE SPEED CONTROL
