Jeep Compass II (2016-2022) turn signal input mux Wiring diagram
This page shows the only wiring diagram for the component.turn signal input mux, which is found in the car Jeep Compass II (2016-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn signal input mux (1 of 1)
BLK WIRE
BODY CONTROL MODULE
BRAKE SIG 1
BRAKE SIG 2
CAN C (+)
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DK GRN/GRN WIRE
DK GRN/YEL WIRE
FUSE 2
FUSE 51
FUSE 53
FUSED B (+)
FUSED IGN
FUSED IGN RUN/START
HAZARD GND
HAZARD SW SENSE
HEADLAMP SW MUX
HEADLAMP SW MUX RTN
HEADLAMP/FOG LAMP SW SIG
HOT AT ALL TIMES
INTEGRATED CENTER STACK SWITCH BANK MODULE
LEFT DAYTIME RUNNING LAMP,
LEFT LICENSE LAMP
LF TURN LAMP DRV
LICENSE PLATE LAMP DRV
PNK/GRN WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
POWERTRAIN CONTROL MODULE
RADIO FREQUENCY HUB MODULE
RED WIRE
RF TURN LAMP DRV
RIGHT DAYTIME RUNNING LAMP
RIGHT END OF DASH)
RIGHT LICENSE LAMP
STEERING COLUMN CONTROL MODULE
STOP LAMP SWITCH (ON BRAKE PEDAL ASSEMBLY)
TAN/WHT WIRE
TURN SIGNAL INPUT MUX
WHT/BLU WIRE
WHT/BRN WIRE
WHT/DK BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/TAN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> TURN SIGNAL INPUT MUX
