Jeep Compass II (2016-2022) lh epb actuator a ctrl Wiring diagram
This page shows the only wiring diagram for the component.lh epb actuator a ctrl, which is found in the car Jeep Compass II (2016-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lh epb actuator a ctrl (1 of 1)
ACTUATOR A CTRL
ACTUATOR B CTRL
ANTI-LOCK BRAKES MODULE (LOWER RIGHT REAR ENGINE COMPT)
BLK WIRE
BODY CONTROL MODULE
CAN C (+)
CAN CH
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/BLU WIRE
DK GRN/BRN WIRE
DK GRN/GRN WIRE
DK GRN/GRY WIRE
DK GRN/ORG WIRE
DK GRN/TAN WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
EPB IND SIG
EPB SW POSITION SIG 1
EPB SW POSITION SIG 2
EPB SW POSITION SIG 3
EPB SW POSITION SIG 4
EPB SW POSITION SIG 5
EPB SW POSITION SIG 6
FUSE 15
FUSE 42
FUSE 53
FUSED B (+)
FUSED IGN
FUSED IGN RUN/START
HOT AT ALL TIMES
LEFT REAR ELECTRIC PARKING BRAKE ACTUATOR
LH EPB
LH EPB ACTUATOR A CTRL
LH EPB ACTUATOR B CTRL
ORG/GRY WIRE
PANEL LAMPS DRV
PARKING BRAKE SWITCH
PNK/GRN WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RH EPB
RH EPB ACTUATOR A CTRL
RH EPB ACTUATOR B CTRL
RIGHT END OF DASH)
RIGHT REAR ELECTRIC PARKING BRAKE ACTUATOR
RUN/START
TAN/RED WIRE
TAN/WHT WIRE
VIO WIRE
YEL WIRE
Go to component -> Park brake release circuit -> LH EPB ACTUATOR A CTRL
