Jeep Compass II (2016-2022) fr drv passive entry Wiring diagram
This page shows the only wiring diagram for the component.fr drv passive entry, which is found in the car Jeep Compass II (2016-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fr drv passive entry (1 of 1)
ANT RTN 1
ANT RTN 2
ANT RTN 3
ANT SIG (2)
ANT SIG 1
ANT SIG 3
BLK WIRE
BODY CONTROL MODULE
CAN CH
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
CTRL OUT
FR DRV PASSIVE ENTRY
FRONT DRIVER EXTERIOR DOOR HANDLE SWITCH
FSD B(+)
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HNDL SW RTN
HNDL SW SENS
IGN RUN/ST
IGN SW SENS
IMMOBILIZER ANT RTN
IMMOBILIZER ANT SIG (+)
IMMOBILIZER CODE ANTENNA
KEYLESS IGNITION NODE MODULE
LINE COMM
PASSIVE ENTRY ANTENNA 1
PASSIVE ENTRY ANTENNA 2
PASSIVE ENTRY ANTENNA 3
PNK/WHT WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT REAR DOOR
SECURITY K
VIO/BLK WIRE
VIO/BRN WIRE
VIO/TAN WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
Go to component -> Passive entry circuit (2 of 2) -> FR DRV PASSIVE ENTRY
