Jeep Compass II (2016-2022) ddct except ddct Wiring diagram
This page shows the only wiring diagram for the component.ddct except ddct, which is found in the car Jeep Compass II (2016-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ddct except ddct (1 of 1)
6 SPEED A/T
6 SPEED A/T 9 SPEED A/T
ANTI-LOCK BRAKES MODULE
BATTERY
BLK WIRE
DDCT EXCEPT DDCT
DK GRN/GRY WIRE
DK GRN/RED WIRE
DK GRN/TAN WIRE
DK GRN/YEL WIRE
DRIVETRAIN CONTROL MODULE
DUAL BATTERY
FROM BATTERY DISTRIBUTION UNIT (DIAGRAM 1 OF 6)
FROM BODY CONTROL MODULE (DIAGRAM 2 OF 6)
FROM FUSE 30 (DIAGRAM 6 OF 6)
FUSE
FUSE 1
FUSE 10
FUSE 15
FUSE 16
FUSE 2
FUSE 24
FUSE 3
FUSE 4
FUSE 5
FUSE 8
FUSE 84
FUSE 87
FUSE 9
GRY/RED WIRE
MEMORY SEAT MODULE
ORG/ WIRE
PNK/GRN WIRE
PNK/GRY WIRE
PNK/VIO WIRE
POWER CONTROL RELAY
POWER DISTRIBUTION CENTER (PDC)
POWER LIFTGATE MODULE
POWER SEAT RELAY
POWERTRAIN CONTROL MODULE
PTC RELAY 1
RADIO, AMPLIFIER
RED WIRE
RED/BRN WIRE
RED/DK GRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/ORG WIRE
RED/YEL WIRE
SEAT HEATER RELAY
SEAT LUMBAR RELAY 2
SHIFT LEVER ASSEMBLY
STARTER RELAY
STARTER RELAY 2
STEERING COLUMN CONTROL MODULE
SUNROOF MOTOR
SUNROOF SHADE MOTOR
TAN/RED WIRE
TO INVERTER MODULE (DIAGRAM 2 OF 6)
TRANSMISSION CONTROL MODULE
VIO/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (5 of 6) -> DDCT EXCEPT DDCT
