Jeep Compass II (2016-2022) ant rtn 2 Wiring diagrams
This page contains all the electrical diagrams for the component. ant rtn 2, in which he is found in the car Jeep Compass II (2016-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ant rtn 2 (1 of 2)
ANT RTN 1 FR DRV PASSIVE ENTRY HNDL SW RTN
ANT RTN 2
ANT RTN 3
ANT RTN 4
ANT RTN 5
ANT SIG (2)
ANT SIG (5)
ANT SIG 1 FR DRV PASSIVE ENTRY HNDL SW SNS
ANT SIG 3
ANT SIG 4
ANT UHF ANT SIG
BLK WIRE
BODY CONTROL MODULE
BOTTOM OF LIFTGATE)
BRAKE SIGNAL 1
CAN C (+)
CLUTCH INTERLOCK SIG
CLUTCH POSITION SENSOR
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN/GRN WIRE
DK GRN/YEL WIRE
ENTRY HNDL SW RTN
ENTRY HNDL SW SNS
FR PASS PASSIVE
FR PASS PASSIVE ENTRY HNDL SW RTN
FR PASS PASSIVE ENTRY HNDL SW SNS
FRONT PASSENGER EXTERIOR DOOR HANDLE SWITCH
FSD B (+) IGN SW SENS
FUSE 53
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
GRY/DK GRN WIRE
GRY/GRN WIRE
GRY/ORG WIRE
GRY/TAN WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
IGN RUN/ST CTRL OUT
PASSIVE ENTRY ANTENNA 4
PASSIVE ENTRY ANTENNA 5
PNK/WHT WIRE
RADIO FREQUENCY HUB MODULE
RED WIRE
REMOTE START ANTENNA
SECURITY K LINE
VIO/BRN WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Passive entry circuit (1 of 2) -> ANT RTN 2
Wiring diagram ant rtn 2 (2 of 2)
ANT RTN 1
ANT RTN 2
ANT RTN 3
ANT SIG (2)
ANT SIG 1
ANT SIG 3
BLK WIRE
BODY CONTROL MODULE
CAN CH
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
CTRL OUT
FR DRV PASSIVE ENTRY
FRONT DRIVER EXTERIOR DOOR HANDLE SWITCH
FSD B(+)
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HNDL SW RTN
HNDL SW SENS
IGN RUN/ST
IGN SW SENS
IMMOBILIZER ANT RTN
IMMOBILIZER ANT SIG (+)
IMMOBILIZER CODE ANTENNA
KEYLESS IGNITION NODE MODULE
LINE COMM
PASSIVE ENTRY ANTENNA 1
PASSIVE ENTRY ANTENNA 2
PASSIVE ENTRY ANTENNA 3
PNK/WHT WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT REAR DOOR
SECURITY K
VIO/BLK WIRE
VIO/BRN WIRE
VIO/TAN WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
Go to component -> Passive entry circuit (2 of 2) -> ANT RTN 2
