Tire pressure monitoring circuit for Jeep Compass I (2006-2010)

6 7 CAN B BUS (+) CAN B BUS (-) B(+) BLK/GRY WIRE BLK/ORG WIRE CLUSTER COM-LIN TIRE PRES MONI LAN COMPUTER DATA LINES SYSTEM ELECTRONICS GROUND GRY WIRE HOT AT ALL TIMES IGN SW OUT (RUN-START) IGN SW OUT (RUN-START) COM-LIN TIRE PRES MONI LAN LEFT FRONT TIRE PRESSURE TRANSPONDER (REAR OF LEFT FRONT FENDER) LEFT REAR TIRE PRESSURE TRANSPONDER (AT LEFT REAR WHEEL WELL) PNK WIRE PNK/GRY WIRE RIGHT REAR TIRE PRESSURE TRANSPONDER (AT RIGHT REAR WHEEL WELL) SENTRY KEY REMOTE ENTRY/ WCM MODULE (RIGHT OF STEERING COLUMN) TIRE PRES BUS TOTALLY INTEGRATED POWER MODULE (LEFT SIDE ENGINE COMPT) TPMS INDICATOR 11 12 CAN B BUS(-) CAN B BUS(+) WHT/GRY WIRE WHT/ORG WIRE WHT/PNK WIRE
