Jeep Compass I (2006-2010) stop lamp cluster switch Wiring diagram
This page shows the only wiring diagram for the component.stop lamp cluster switch, which is found in the car Jeep Compass I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop lamp cluster switch (1 of 1)
2 1 (PATRIOT) (COMPASS)
ACTIVATION LAMP RELAY
ALL WHEEL DRIVE CONTROL MODULE (AWD)
ANTI-LOCK BRAKES MODULE
BATTERY
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DOME LAMP (RECHARGEABLE)
ELECTRONICS
FROM FUSE 24 (DIAGRAM 1 OF 4)
FROM FUSE 35 (DIAGRAM 2 OF 4)
FUSE
FUSE 2 FUSE 3
FUSE 34
FUSE 35
FUSE 4
FUSE/ RELAY BLOCK (LEFT FRONT ENGINE COMPT)
GRN WIRE
HEATED SEATS MODULE
HIGH MOUNTED STOP LAMP
IGNITION FUSE
IGNITION SW OUT (RUN)
IGNITION SW OUTPUT (RUN-ACC)
INSTRUMENT PANEL POWER OUTLET
LT GRN WIRE
ORG/ WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
PNK/YEL WIRE
REAR WIPER MOTOR
RED WIRE
STOP LAMP CLUSTER SWITCH
STOP LAMP SW OUT
STOP LAMP SWITCH
SUNROOF MOTOR
TO AC POWER OUTLET (DIAGRAM 4 OF 4)
TO FUSE 18 (DIAGRAM 3 OF 4)
TO FUSE 2 (DIAGRAM 2 OF 4)
TO IGNITION SWITCH (DIAGRAM 3 OF 4)
TO INVERTER MODULE (DIAGRAM 4 OF 4)
TOTALLY INTEGRATED POWER MODULE (LEFT SIDE ENGINE COMPT)
W/ HEATED SEATS
W/ LAMP ACTIVATION
W/O LAMP DK ACTIVATION
W/O SUNROOF, SUNROOF, W/O POWER W/ POWER INVERTER INVERTER
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> STOP LAMP CLUSTER SWITCH
